10G CWDM SFP+
- Brand: NVOC
- Type: NV-10G-CWDM
●Supports 9.95 to 11.3Gb/s bit rates
●Duplex LC connector
●Hot pluggable SFP+ footprint
●Cooled 1470nm~1550nm EML transmitter, APD Receiver
●Applicable for 80km SMF connection
●Low power consumption, < 1.5W
●Digital Diagnostic Monitor Interface
●Optical interface compliant to IEEE 802.3ae 10GBASE-ZR
●Electrical interface compliant to SFF-8431
●Operating case temperature:
Commerical:0 to 70 °C
Industrial:-20 to 80 °C
Applications
●10GBASE-ZR at 10.3125Gbps
●10G Ethernet
●Other optical links
Product Descriptions
CD80 CWDM 10Gbps SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 80km. This transceiver consists of two sections: The transmitter section incorporates a CWDM EML laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
Package
Ordering Information
|
Part Number |
Description |
|
NV-XX-CD10 |
SFP+,9.95 to 10.5Gb/s, CWDM, 10km, 0~70℃, with Digital Diagnostic Monitor |
|
NV-XX-ID10 |
SFP+,9.95 to 10.5Gb/s, CWDM, 10km, -40~80℃, with Digital Diagnostic Monitor |
|
Xx means: |
27=1270nm,29=1290nm…59=1590nm，61=1610nm (20nm Spacing) |
|
Part Number |
Description |
|
NV-XX-CD20 |
SFP+,9.95 to 10.5Gb/s, CWDM, 20km, 0~70℃, with Digital Diagnostic Monitor |
|
NV-XX-ID20 |
SFP+,9.95 to 10.5Gb/s, CWDM, 20km, -40~80℃, with Digital Diagnostic Monitor |
|
Xx means: |
27=1270nm,29=1290nm…59=1590nm，61=1610nm (20nm Spacing) |
|
|
|
|
Part Number |
Description |
|
NV-XX-CD40 |
SFP+,9.95 to 10.5Gb/s, CWDM, 40km, 0~70℃, with Digital Diagnostic Monitor |
|
NV-XX-ID40 |
SFP+,9.95 to 10.5Gb/s, CWDM, 40km, -20~80℃, with Digital Diagnostic Monitor |
|
Xx means: |
27=1270nm,29=1290nm…43=1430nm，61=1610nm (20nm Spacing) |
|
Part Number |
Description |
|
NV-XX-CD80 |
SFP+,9.95 to 11.3Gb/s, CWDM, 80km, 0~70℃, with Digital Diagnostic Monitor |
|
NV-XX-ID80 |
SFP+,9.95 to 11.3Gb/s, CWDM, 80km, -20~80℃, with Digital Diagnostic Monitor |
|
Xx means: |
47=1470nm,49=1490nm…53=1530nm，55=1550nm (20nm Spacing) |
