Technical specification
Item |
Parameter |
|
Cable Scope |
3.0 x 2.0 mm and 1.6*2.0mm Bow-type Drop Cable |
|
Size: |
51*9*7.55mm |
|
Fiber Diameter |
125μm ( 652 & 657 ) |
|
Coating Diameter |
250μm |
|
Mode |
SM |
|
Operation Time |
about 15s(exclude fiber presetting) |
|
Insertion Loss |
≤ 0.3dB(1310nm & 1550nm) |
|
Return Loss |
≤ -50dB for UPC, ≤ 55dB for APC |
|
Success Rate |
>98% |
|
Reusable Times |
>10 times |
|
Tighten Strength of Naked Fiber |
>5 N |
|
Tensile Strength |
>50 N |
|
Temperature |
-40 ~ +85 C |
|
On-line Tensile Strength Test (20 N) |
IL ≤ 0.3dB |
|
Mechanical Durability(500 times) |
IL ≤ 0.3dB |
|
Drop Test(4m concrete floor, once each direction, three times total) |
IL ≤ 0.3dB |
|
Relevant Solutions
- Easy operating, The connector can be directly used in ONU, also with fasten strength more than 5 kg, it is widely used in FTTH project of network revolution. It also reduce the use of sockets and adapters, save cost of project.
- With 86 standard socket and adapter, the connector makes connection between drop cable and patch cord. The 86 standard socket provides complete protection with its unique design.
- Applicable to connection with field mountable indoor cable, pigtail, patch cord and transformation of patch cord in data room and directly used in specific ONU.
