SFP+-SR

10Gbps SFP+ Transceiver, 300m Reach

Features

►Optical interface compliant to IEEE 802.3ae 10GBASE-SR

►Electrical interface compliant to SFF-8431

►Hot Pluggable

►850nm VCSEL transmitter, PIN photo-detector

►Maximum link length of 300m on 2000MHz/km MMF

►Operating case temperature: 0 to 70℃

►Low power consumption

►All-metal housing for superior EMI performance

►Advanced firmware allow customer system encryption information to be stored in transceiver

►Cost effective SFP+ solution, enables higher port densities and greater bandwidth

Applications

►10GBASE-SR at 10.3125Gbps

►10GBASE-SW at 9.953Gbps

►Other optical links
