Ø  10G Ethernet

Ø  InfiniBand, Fiber Channel 4G/8G/10G

Ø  Sonet Multiplatform support

Ø  High Performance Computing Clusters

Ø  High End Servers

Ø  Metro Network Switch/Cross Connect

2. Features

Ø  Active Copper (Equipped with chipset as signal repeater) (Cable Length: 0.5~15m)

Ø  Support for multi-gigabit data rates up to 10.5Gbps

Ø  Data rates backward compatible to 1Gbps

Ø  Hot-pluggable SFP 20PIN footprint

Ø  I/O Connector designed for high speed differential signal applications

Ø  Improved Pluggable Form Factor(IPF) compliant for enhanced EMI/EMC performance

Ø  Compatible with industry standard SFP cages +Switches

Ø  EEPROM signature can be customized.

Ø  Low Power Consumption < 0.5W

Ø  Temperature Range: 0~ 70 °C

Ø  RoHS-6 Compliant

3. Description

High speed SFP+ Direct Attach Cable (DAC) provides high performance in 10 Gigabit Ethernet (10GbE) network applications, using an enhanced SFP+ connector to send 10Gbps data through one paired transmitters and receivers over a thin twinax cable. They are compliant with electrical standards SFF-8431, SFF-8083 and mechanical standard SFF-8432, EEPROM standard SFF-8472.

4. Standard

Ø  Compliant with electrical standards SFF-8431, SFF-8083

Ø  Compliant with mechanical standard SFF-8432

Ø  Compliant with EEPROM standard SFF-8472

Ø  RoHS Compliant
