Features

►Support Multi Rate 1.25-6.25Gbps

►Hot Pluggable SFP+ footprint

►1310nm FP transmitter, PIN photo-detector

►Transmission distance up to 2km on 9/125 μm SMF

►Digital Status monitoring Interface

►Duplex LC connector

►RoHS compliant and Lead Free

►Metal enclosure for lower EMI

►Single 3.3V power supply

►Power dissipation <2.5W

►Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472

►Operating case temperature:

►Standard :  0 to +70℃

►Industrial : -40 to +85℃

Applications

►High-speed storage area networks

►Computer cluster cross-connect

►Custom high-speed data pipes

►LTE optical repeater application

Product description

   SFP+-6.25G-02 is a high performance, cost effective modules, which is supporting multi-rate

1.25-6.25Gbps, and transmission distance up to 2km on SM fiber. The transceiver consists of two

sections: The transmitter section incorporates a 1310nm FP driver and re-timer. The receiver

section consists of a PIN photodiode integrated with a transimpedance preamplifier (TIA). The

module is hot pluggable into the 20-pin connector. The high-speed electrical interface is base on low

voltage logic, with nominal 100 Ohms differential impedance and AC coupled in the module.

Pin definition

  The SFP+ modules are hot-pluggable. Hot pluggable refers to plugging in or unplugging a module while the host board is powered.  The SFP+ host connector is a 0.8 mm pitch 20 position right angle improved connector specified by SFF-8083, or stacked connector with equivalent with equivalent electrical performance.   Host PCB contact assignment is shown in Figure 2 and contact definitions are given in Table 2.

   SFP+ module contacts mates with the host in the order of ground, power, followed by signal as illustrated by Figure 3 and the contact sequence order listed in Table 2.

Package



Ordering information

Part Number	Product Description
6.25G-01	850nm, 1.25~6.25Gbs, 300m,   0ºC ~ +70ºC
6.25G-01I	850nm, 1.25~6.25Gbs, 300m,   -40ºC ~ +85ºC
6.25G-05	1310nm, 1.25~6.25Gbs, 500m,   0ºC ~ +70ºC
6.25G-05I	1310nm, 1.25~6.25Gbs,500m,   -40ºC ~ +85ºC
6.25G-02	1310nm, 1.25~6.25Gbs, 2km,   0ºC ~ +70ºC
6.25G-02I	1310nm, 1.25~6.25Gbs, 2km,   -40ºC ~ +85ºC
6.25G-10	1310nm, 1.25~6.25Gbs, 10km,   0ºC ~ +70ºC
6.25G-10I	1310nm, 1.25~6.25Gbs, 10km,   -40ºC ~ +85ºC
6.25G-02A/B	1270/1330nm, 1.25~6.25Gbs, 2km,   0ºC ~ +70ºC
6.25G-02A/BI	1270/1330nm, 1.25~6.25Gbs, 2km,   -40ºC ~ +85ºC
6.25G-02A/B+	1270/1330nm, 1.25~6.25Gbs, 2km,   0ºC ~ +70ºC
6.25G-02A/B+I	1270/1330nm, 1.25~6.25Gbs, 2km,   -40ºC ~ +85ºC
