2.5G Duplex SFP
- Brand: NVOC
- Type: NV-OC48
2.488Gbps SFP Optical Transceiver
►Up to 2.488Gb/s bi-directional data links
►1310nm FP laser and PIN photodetector for 2km transmission
►Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
►Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
►Compatible with RoHS
►+3.3V single power supply
►Operating case temperature:
Standard : 0 to +70°C
Industrial : -40 to +85°C
Applications
►SDH STM-16 and SONET OC-48 system
►2X Fiber Channel
►Switch to Switch interface
►Switched backplane applications
►Router/Server interface
►Other optical transmission systems
Description
The SFP transceivers are high performance, cost effective modules supporting dual data-rate of 2.488Gbps and different transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Pacakge
Ordering information
Part Number
Product Description
OC48-01
850nm, 2.488Gbps, 300m, 0ºC ~ +70ºC
OC48-01D
850nm, 2.488Gbps, 300m, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-01I
850nm, 2.488Gbps, 300m, -20ºC ~ +85ºC
OC48-01ID
850nm, 2.488Gbps, 300m, -20ºC ~ +85ºC, With Digital Diagnostic Monitoring
OC48-02
1310nm, 2.488Gbps, 2km, 0ºC ~ +70ºC
OC48-02D
1310nm, 2.488Gbps, 2km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-02I
1310nm, 2.488Gbps, 2km, -40ºC ~ +85ºC
OC48-02ID
1310nm, 2.488Gbps, 2km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring
OC48-10
1310nm, 2.488Gbps, 10km, 0ºC ~ +70ºC
OC48-10D
1310nm, 2.488Gbps, 10km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-10I
1310nm, 2.488Gbps, 10km, -40ºC ~ +85ºC
OC48-10ID
1310nm, 2.488Gbps, 10km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring
OC48-40
1310nm, 2.488Gbps, 40km, 0ºC ~ +70ºC
OC48-40D
1310nm, 2.488Gbps, 40km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-40I
1310nm, 2.488Gbps, 40km, -40ºC ~ +85ºC
OC48-40ID
1310nm, 2.488Gbps, 40km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring
OC48-80
1550nm, 2.488Gbps, 80km, 0ºC ~ +70ºC
OC48-80D
1550nm, 2.488Gbps, 80km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-80I
1550nm, 2.488Gbps, 80km, -40ºC ~ +85ºC
OC48-80ID
1550nm, 2.488Gbps,80km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring
OC48-120
1550nm, 2.488Gbps, 120km, 0ºC ~ +70ºC
OC48-120D
1550nm, 2.488Gbps, 120km, 0ºC ~ +70ºC, With Digital Diagnostic Monitoring
OC48-120I
1550nm, 2.488Gbps, 120km, -40ºC ~ +85ºC
OC48-120ID
1550nm, 2.488Gbps,120km, -40ºC ~ +85ºC, With Digital Diagnostic Monitoring
