DP1.4 Full 8k Fiber Optical Extender

FEATURES：

1）  CWDM Single Fiber Technology.

2）  1270/1290/1310/1330/1490/1550nm DFB lasers inside

3）  Compliant with DP1.2 and DP1.4 ;

4）  AUX signal Transparent pass-through;

5）  Extension distance up to 1000 meters

6）  Transmit signal over one Single-mode Fiber

7）  Uncompressed video up to 32.4Gb/s data rate;

8）  Maximum resolution up to8k@30Hz  ;

9）  1xLC Fiber Connector;

10）Bi-directional RS-232 and IR extension.

11）Zero frame delay.

12）HDR and Dolby Vision support;

13）DC +12V 1A Power Supply

APPLICATIONS:：

1）  Rental and staging；

2）  Long distance HDMI,DVI signal transmission

3）  Professional AV system, conference rooms.

DETAILS:

   The DP14-601S01-T/R is an uncompressed full 8k UHD video fiber extender pair, which resolution is up to 8k@ 30Hz 4:4:4. The extender can transmit the DP1.4 signal with 32.4Gb/s over one Single-mode fiber, and the distance is up to 1000m.   The extender pair is using CWDM technology; there are 6 wavelength lasers in the extender pair. The data rate of the 1270nm/1290nm/1310nm/1330nm lasers are 8.1Gb/s, these 4 CWDM lasers transmit the DP four lanes signal from TX to RX unit, The 1490nm/1550nm laser data rate is 1.25Gb/s, which transmit the AUX,IR and RS232 signal Bi-directionally. the unit offers transparent AUX signal transmission bi-directionally.
