1.25G BIDI LC SFP
- Brand: NVOC
- Type: NV-OC24A/B
►Dual data-rate of 1.25Gbps/1.063Gbps operation
►1310nm FP laser and PIN photodetector for 10km transmission
►Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
►Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
►Compatible with SONET OC-24-LR-1
►Compatible with RoHS
►+3.3V single power supply
►Operating case temperature:
Standard : 0 to +70°C
Applications
►Gigabit Ethernet
►Fiber Channel
►Switch to Switch interface
►Switched backplane applications
►Router/Server interface
►Other optical transmission systems
DescriptionThe BIDI SFP transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 10km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Package
Ordering information
Part Number
Product Description
OC24-3AS
1310nm, 1.25Gbps, SC,3km, 0°C~+70°C
OC24-3ASD
1310nm, 1.25Gbps, SC,3km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-3A
1310nm, 1.25Gbps, LC,3km, 0°C~+70°C
OC24-3AD
1310nm, 1.25Gbps, LC,3km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-20AS
1310nm, 1.25Gbps, SC,20km, 0°C~+70°C
OC24-20ASD
1310nm, 1.25Gbps, SC,20km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-20A
1310nm, 1.25Gbps, LC,20km, 0°C~+70°C
OC24-20AD
1310nm, 1.25Gbps, LC,20km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-40AS
1310nm, 1.25Gbps, SC,40km, 0°C~+70°C
OC24-40ASD
1310nm, 1.25Gbps, SC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-40A
1310nm, 1.25Gbps, LC,40km, 0°C~+70°C
OC24-40AD
1310nm, 1.25Gbps, LC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-60AS
1310nm, 1.25Gbps, SC,60km, 0°C~+70°C
OC24-60ASD
1310nm, 1.25Gbps, SC,60km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-60A
1310nm, 1.25Gbps, LC,60km, 0°C~+70°C
OC24-60AD
1310nm, 1.25Gbps, LC,60km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-80AS
1490nm, 1.25Gbps, SC,80km, 0°C~+70°C
OC24-80ASD
1490nm, 1.25Gbps, SC,80km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-80A
1490nm, 1.25Gbps, LC,80km, 0°C~+70°C
OC24-80AD
1490nm, 1.25Gbps, LC,80km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-100AS
1490nm, 1.25Gbps, SC,100km, 0°C~+70°C
OC24-100ASD
1490nm, 1.25Gbps, SC,100km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-100A
1490nm, 1.25Gbps, LC,100km, 0°C~+70°C
OC24-100AD
1490nm, 1.25Gbps, LC,100km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-120AS
1490nm, 1.25Gbps, SC,120km, 0°C~+70°C
OC24-120ASD
1490nm, 1.25Gbps, SC,120km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-120A
1490nm, 1.25Gbps, LC,120km, 0°C~+70°C
OC24-120AD
1490nm, 1.25Gbps, LC,120km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-140AS
1490nm, 1.25Gbps, SC,140km, 0°C~+70°C
OC24-140ASD
1490nm, 1.25Gbps, SC,140km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-140A
1490nm, 1.25Gbps, LC,140km, 0°C~+70°C
OC24-140AD
1490nm, 1.25Gbps, LC,140km, 0°C~+70°C, With Digital Diagnostic Monitoring
Part Number
Product Description
OC24-160AS
1490nm, 1.25Gbps, SC,160km, 0°C~+70°C
OC24-160ASD
1490nm, 1.25Gbps, SC,160km, 0°C~+70°C, With Digital Diagnostic Monitoring
OC24-160A
1490nm, 1.25Gbps, LC,160km, 0°C~+70°C
OC24-160AD
1490nm, 1.25Gbps, LC,160km, 0°C~+70°C, With Digital Diagnostic Monitoring
