MPO OM3 MULTIMODE CONNECTOR With this MPO fiber cable, you are ready for deployment in any multimode 10 GB 50/125 MPO network. 10 GB OM3 fiber optic patch cables feature an extremely high bandwidth--almost 3x that of a typical multimode cable. The push-on connectors hold the cable securely in place. This multimode, MPO fiber cable is comprised of 8 fibers or 4 duplex channels within each connector. These high density cables are perfect when you have limited space and but still want that great fiber connection.

Specification:

Insertion Loss:<0.3dB

Operating Wavelength:SM

Cable diameter:3mm

Minimum bend radius:3.8cm

Plug: ceramic ferrule

Material:PVC

Insertion and removal times: >1000 times

Working temperature: -40°C~85°C

Tensile strength: ≥200N

Vibration : <0.1db

Jacket: OFNR (Riser-Rated)

Features:

Low insertion loss and back reflection loss

Good repeatability

Good exchangeability

Good Durability

Interpolation performance is good

High temperature stability

Immune to Electrical Interference

100% Optically Inspected and Tested for Insertion Loss

Application:

Optical LAN

Optical fiber communication systems

Test equipment

Fiber CATV

Fiber Network Deployments

Fast Ethernet

Gigabit Ethernet

Other Data Applications Requiring High Transfer Rates
