HDMI2.0 Full 4k Fiber Optical Extender

FEATURES：

1） CWDM Single Fiber Technology.

2） 1270/1290/1310/1330/1490/1550nm DFB lasers inside

3） Compliant with HDMI2.0,HDMI1.4 ;

4） Compliant with HDCP2.2(Transparent pass-through);

5） Extension distance up to 300 meters.

6） Transmit signal over one Single-mode Fiber or OM3 multimode Fiber

7） Uncompressed video up to 18Gb/s data rate(600M Hz pixel clock);

8） 4096 x 2160@60Hz/4:4:4 maximum resolution(600MHz);

9） 1xLC Fiber Connector;

10）Bi-directional RS-232 and IR extension;

11）Zero frame delay;

12）HDR and Dolby Vision support;

13）DC +12V 1A Power Supply

APPLICATIONS:：

1） Rental and staging；

2） Long distance HDMI,DVI signal transmission

3） Professional AV system, conference rooms.

DETAILS:

   The HDMI-20S01-T/R is an uncompressed full 4k UHD video fiber extender pair, which resolution is up to 4096*2016@ 60Hz 4:4:4. The extender can transmit the HDMI2.0 signal with 18 GB/s over one Single-mode or multimode fiber to a distance of up to 300m.

   The extender pair is using CWDM technology; there are 6 wavelength lasers in the extender pair. The data rate of the 1270nm/1290nm/1310nm/1330nm lasers are 6Gb/s, these 4 CWDM lasers transmit the HDMI TMDS signal from TX to RX unit, The 1490nm/1550nm laser data rate is 1.25Gb/s, which transmit the EDID,HDCP,IR and RS232 signal Bi-directionally.

   The unit offers transparent EDID and HDCP signal transmission bi-directionally. So the unit is compliant with the HDCP2.2 well.

   The unit support both HDR and Dolby Vision in the HDMI signal , which its frame bandwidth of 18Gb/s maximum.
